Zebra Wired 1D/2D barcode scanner

Zebra DS2208 – Wired 1D/2D barcode scanner (USB kit + stand, Black)

The affordable and simple 1D/2D scanner: just plug it in and start scanning.

Manufacturer part no. DS2208-SR7U3200SGW · EAN 8596375197442 · Launched in 2017 In stock Delivery in 2 to 3 days
https://www.r2scan.com/web/image/product.template/1055/image_1920?unique=c955158
(0 review)

Zebra barcode scanner DS2208, connection: Corded USB, range: Standard, colour black, connection: Corded USB.

Key specifications of this reference:

  • Connection: Corded USB
  • Range: Standard
  • Keypad: Without keypad
  • Colour: Black
  • Ships with: Kit USB + support (spiralé)

90.00 € excl. VAT 108.90 EUR 90.00 €

108.90 € incl. VAT

Prix sur demande

  • Keyboard type
  • Connection
  • Range
  • Reading
  • Ships with
  • Colour
  • Keyboard
  • Use
  • Brand
  • Famille

This combination does not exist.

Request a price
This reference
Manufacturer part no.
DS2208-SR7U3200SGW
EAN
8596375197442
Brand
Zebra
Family
Zebra DS2208
Launched in
2017
Key specifications
Type
Handheld bar code reader
Scanner type
1D/2D
Sensor type
LED
Linear (1D) barcodes supported
Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, U.P.C.
2D (matrix & stacked) barcodes supported
Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, TLC-39
Optical sensor resolution (W x H)
640 x 480 pixels
Working distance
36.8 cm
Wavelength
645 nm
Tilt reading angle
-65 - 65°
Pitch reading angle
-65 - 65°
Yaw reading angle
-65 - 65°
Motion tolerance (cm/s)
13
Connectivity technology
Wired
Standard interfaces
USB, RS-232, RS-485, Keyboard wedge
All specifications

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share

See all versions of this family Zebra DS2208 (9)

Compatible accessories

The affordable and simple 1D/2D scanner: just plug it in and start scanning.

The Zebra DS2208 brings 2D scanning within reach of every point of sale. It scans 1D and 2D codes – whether printed or displayed on a smartphone screen – first time, using a ‘point-and-shoot’ method that requires no training.

Pre-configured at the factory and supplied with a cable featuring automatic interface detection, it is ready to use straight out of the box. Supplied as a USB kit with a stand for hands-free use.

Highlights

  • 1D/2D scanning and on-screen codes
  • Plug-and-play, auto-detecting USB cable
  • Lightweight and ergonomic for a full day’s use
  • USB kit with stand
  • Drops of 1.5 m, IP42

Ideal for : Checkouts, shops, pharmacies, hospitality, tablet-based points of sale.

Technical specifications

Scanning
TypeHandheld bar code reader
Scanner type1D/2D
Sensor typeLED
Linear (1D) barcodes supportedCodabar, Code 11, Code 128, Code 39, Code 93, EAN-13, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, U.P.C.
2D (matrix & stacked) barcodes supportedAztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, TLC-39
Optical sensor resolution (W x H)640 x 480 pixels
Working distance36.8 cm
Wavelength645 nm
Tilt reading angle-65 - 65°
Pitch reading angle-65 - 65°
Yaw reading angle-65 - 65°
Motion tolerance (cm/s)13
Ports & interfaces
Connectivity technologyWired
Standard interfacesUSB, RS-232, RS-485, Keyboard wedge
Performance
International Protection (IP) codeIP42
LED indicatorsYes
Product colourBlack
CertificationEN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07 IEC 62471 EN 55022 (Class B); EN 55032 (Class B) EN 55024 EN 61000-3-2 EN 61000-3-3 47 CFR Part 15, Subpart B, Class B ICES-003 Issue 6, Class B
Power
Power source typeDC
Battery life100 h
AC adapter output voltage5 V
Power consumption250 mA
Weight & dimensions
Width66 mm
Depth99 mm
Height165 mm
Weight161.6 g
Packaging data
Cables includedMicro-USB
Charging baseNo
Operational conditions
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)5 - 95%
Battery
Battery technologyLithium-Ion (Li-Ion)
Battery capacity2400 mAh
Technical details
Compliance certificatesRoHS
Logistics data
Harmonized System (HS) code84716070
