Zebra Bluetooth ring scanner

Zebra RS5100 – Bluetooth ring scanner (SE4770, Bluetooth)

The RS5100: the most versatile Bluetooth ring scanner, with five wearing styles and two scanning engines.

Manufacturer part no. RS51C0-TBSNWR · EAN 5715063270097 · Launched in 2020 Available on order Delivery in 2 to 3 days
https://www.r2scan.com/web/image/product.template/1321/image_1920?unique=43c26c9
(0 review)

Zebra wearable barcode scanner RS5100, imager FlexRange, connection: Bluetooth (cordless), battery: Standard, colour black, battery: Standard, colour noir.

Key specifications of this reference:

  • Scan engine: FlexRange
  • Scan range: Flex (standard + long range)
  • Connection: Bluetooth (cordless)
  • Keypad: Without keypad
  • Battery: Standard
  • Colour: Black

795.00 € excl. VAT 961.95 EUR 795.00 €

961.95 € incl. VAT

Prix sur demande

  • Scan range
  • Scan engine
  • Keyboard type
  • Connection
  • Reading
  • Colour
  • Keyboard
  • Use
  • Brand
  • Battery
  • Mounting
  • Famille

This combination does not exist.

Request a price
This reference
Manufacturer part no.
RS51C0-TBSNWR
EAN
5715063270097
Brand
Zebra
Family
Zebra RS5100
Launched in
2020
Key specifications
Type
Wearable bar code reader
Scanner type
1D/2D
Sensor type
Laser
Linear (1D) barcodes supported
Code 11, Code 128, Code 39, Code 93, GS1 DataBar, MSI, UPC-A, UPC-E
2D (matrix & stacked) barcodes supported
Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Optical sensor resolution (W x H)
1280 x 960 pixels
Light levels (direct sunlight)
0 - 107639 lx
Wavelength
655 nm
Tilt reading angle
-60 - 60°
Pitch reading angle
-60 - 60°
Yaw reading angle
0 - 360°
Connectivity technology
Wireless
Standard interfaces
Bluetooth
Bluetooth version
5.2
All specifications

Terms and Conditions
30-day money-back guarantee
Shipping: 2-3 Business Days

Share

See all versions of this family Zebra RS5100 (8)

Compatible accessories

The RS5100: the most versatile Bluetooth ring scanner, with five wearing styles and two scanning engines.

The Zebra RS5100 is a lightweight Bluetooth ring scanner that can be worn on one finger, two fingers or on the back of the hand. It is available with a standard SE4710 engine or an SE4770 engine for difficult barcodes, a standard or extended battery, and a single or dual trigger.

NFC pairing with a single tap using WT5400/WT6400 terminals and Zebra mobile terminals.

Highlights

  • Bluetooth, NFC pairing
  • SE4710 or SE4770
  • Standard or extended battery, replaceable
  • Five ways to wear it
  • Single or double trigger

Ideal for : Order fulfilment, sorting, e-commerce.

Technical specifications

Scanning
TypeWearable bar code reader
Scanner type1D/2D
Sensor typeLaser
Linear (1D) barcodes supportedCode 11, Code 128, Code 39, Code 93, GS1 DataBar, MSI, UPC-A, UPC-E
2D (matrix & stacked) barcodes supportedAztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Optical sensor resolution (W x H)1280 x 960 pixels
Light levels (direct sunlight)0 - 107639 lx
Wavelength655 nm
Tilt reading angle-60 - 60°
Pitch reading angle-60 - 60°
Yaw reading angle0 - 360°
Ports & interfaces
Connectivity technologyWireless
Standard interfacesBluetooth
Bluetooth version5.2
Bluetooth Low Energy (BLE)Yes
Near Field Communication (NFC)Yes
Performance
LED indicatorsYes
Product colourBlack
Power
Power source typeBattery
Battery typeBuilt-in battery
Weight & dimensions
Width28 mm
Depth21 mm
Height61 mm
Weight70 g
Operational conditions
Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-40 - 60 °C
Operating relative humidity (H-H)5 - 95%
Battery
Battery technologyLithium-Ion (Li-Ion)
Battery capacity480 mAh

Why R2Scan

Authorised reseller, stock in Belgium, device configuration and commissioning, technical support and in-house repair workshop.
