Zebra
High-resolution industrial label printer
Zebra ZT610 – High-resolution industrial label printer (203 dpi)
The ZT610: the top-of-the-range 4" industrial printer, shown here at 600 dpi for micro-labels.
Manufacturer part no. ZT61042-T2E0100Z
· EAN 8596375178311
· Launched in 2017
Available on order
Delivery in 2 to 3 days
Zebra industrial label printer ZT610, Thermal transfer, 203 dpi, Thermal transfer.
Key specifications of this reference:
- Technology: Thermal transfer
- Resolution: 203 dpi
- Interfaces: Bluetooth + Ethernet + Serial + USB
This reference
- Manufacturer part no.
- ZT61042-T2E0100Z
- EAN
- 8596375178311
- Brand
- Zebra
- Family
- Zebra ZT610
- Launched in
- 2017
Key specifications
- Print technology
- Thermal transfer
- Maximum resolution
- 203 x 203 DPI
- Print speed
- 356 mm/sec
- Maximum printing width
- 10.4 cm
- Vertical printing
- Yes
- Rotated printing
- Yes
- Ribbon width
- 11 cm
- Ribbon length
- 450 m
- Maximum label length
- 762 m
- Maximum roll diameter
- 20.3 cm
- Media thickness
- 0.058 - 0.25 mm
- Core diameter
- 7.62 cm
- Connectivity technology
- Wired & Wireless
- Ethernet LAN
- Yes
Compatible accessories
Economical wax thermal transfer ribbon
Zebra Ruban cire 1600 – Economical wax thermal transfer ribbon (18 rolls, Industrial 4", 110 mm)
143.16 €
Wax thermal transfer ribbon
Zebra Ruban cire 2100 – Wax thermal transfer ribbon (Industrial 4", 60 mm)
95.44 €
Wax thermal transfer ribbon
Zebra Ruban cire 2100 – Wax thermal transfer ribbon (Industrial 4", 89 mm)
141.74 €
Wax thermal transfer ribbon
Zebra Ruban cire 2100 – Wax thermal transfer ribbon (Industrial 4", 102 mm)
162.15 €
Wax thermal transfer ribbon
Zebra Ruban cire 2100 – Wax thermal transfer ribbon (Industrial 4", 110 mm)
174.87 €
Wax thermal transfer ribbon
Zebra Ruban cire 2300 – Wax thermal transfer ribbon (12 rolls, Industrial 4", 450 m, 40 mm)
54.61 €
Wax thermal transfer ribbon
Zebra Ruban cire 2300 – Wax thermal transfer ribbon (12 rolls, Industrial 4", 450 m, 60 mm)
82.09 €
Wax thermal transfer ribbon
Zebra Ruban cire 2300 – Wax thermal transfer ribbon (12 rolls, Industrial 4", 450 m, 83 mm)
113.34 €
Wax thermal transfer ribbon
Zebra Ruban cire 2300 – Wax thermal transfer ribbon (12 rolls, Industrial 4", 450 m, 89 mm)
121.50 €
Wax thermal transfer ribbon
Zebra Ruban cire 2300 – Wax thermal transfer ribbon (12 rolls, Industrial 4", 450 m, 102 mm)
139.22 €
Wax thermal transfer ribbon
Zebra Ruban cire 2300 – Wax thermal transfer ribbon (12 rolls, Industrial 4", 450 m, 110 mm)
150.38 €
Wax-resin thermal transfer ribbon
Zebra Ruban cire-résine 3200 – Wax-resin thermal transfer ribbon (6 rolls, Industrial 4", 450 m, 40 mm)
56.59 €
Wax-resin thermal transfer ribbon
Zebra Ruban cire-résine 3200 – Wax-resin thermal transfer ribbon (6 rolls, Industrial 4", 450 m, 102 mm)
143.94 €
Resin thermal transfer ribbon
Zebra Ruban résine 5095 – Resin thermal transfer ribbon (6 rolls, Industrial 4", 450 m, 40 mm)
115.76 €
Economical direct thermal paper labels
Zebra Z-Perform 1000D – Economical direct thermal paper labels (51 × 32 mm, 10 rolls, 4 790 étiquettes, 76 mm)
145.85 €
Economical direct thermal paper labels
Zebra Z-Perform 1000D – Economical direct thermal paper labels (100 × 50 mm, 4 rolls, 3 000 étiquettes, 76 mm)
98.54 €
Polyolefin thermal transfer labels
Zebra PolyO 3100T – Polyolefin thermal transfer labels (102 × 76 mm, 1 890 étiquettes, Industrial 4")
212.65 €
Polyolefin thermal transfer labels
Zebra PolyO 3000T – Polyolefin thermal transfer labels (102 × 152 mm, 4 rolls)
237.09 €
Economical thermal transfer paper labels
Zebra Z-Perform 1000T – Economical thermal transfer paper labels (76 × 25 mm, 6 rolls, 5 180 étiquettes, 76 mm)
205.62 €
Economical thermal transfer paper labels
Zebra Z-Perform 1000T – Economical thermal transfer paper labels (102 × 51 mm, 4 rolls, 2 590 étiquettes, 76 mm)
151.49 €
Thermal transfer polyethylene labels
Zebra PolyE 3100T – Thermal transfer polyethylene labels (102 × 76 mm, 4 rolls, 1 890 étiquettes, 76 mm)
159.01 €
Thermal transfer polyethylene labels
Zebra PolyE 3100T – Thermal transfer polyethylene labels (102 × 102 mm, 4 rolls, 1 432 étiquettes, 76 mm)
159.01 €
Thermal transfer polypropylene labels
Zebra PolyPro 3000T – Thermal transfer polypropylene labels (102 × 152 mm, 2 rouleaux, 950 étiquettes, 76 mm)
97.21 €
Synthetic thermal transfer labels
Zebra Z-Trans 8000T – Synthetic thermal transfer labels (51 × 25 mm, 10 rolls, 5 180 étiquettes, Industrial 4")
206.15 €
Thermal transfer paper labels
Zebra Z-Select 2000T – Thermal transfer paper labels (102 × 152 mm, 4 rolls, 950 étiquettes, 76 mm)
77.18 €
Synthetic thermal transfer labels
Zebra Z-Trans 8000T – Synthetic thermal transfer labels (100 × 50 mm, 4 rolls, 2 820 étiquettes, Industrial 4")
77.18 €
Economical direct thermal paper labels
Zebra Z-Perform 1000D – Economical direct thermal paper labels (102 × 152 mm, 4 rolls, 950 étiquettes, 76 mm)
96.85 €
Economical thermal transfer paper labels
Zebra Z-Perform 1000T – Economical thermal transfer paper labels (102 × 152 mm, 4 rolls, 950 étiquettes, 76 mm)
79.06 €
Printer spare part
Zebra KIT PRINTHEAD 203 DPI ZT610 ZT610R
504.00 €
Printer spare part
Zebra KIT PRINTHEAD 300 DPI ZT610 ZT610R
560.00 €
Printer spare part
Zebra KIT PRINTHEAD 600 DPI ZT610 ZT610R
717.00 €
Printer spare part
Zebra Kit Printhead 203 dpi ZT620
623.00 €
Printer spare part
Zebra Kit Platen Roller ZT610 ZT610R
56.00 €
Printer spare part
Zebra interface card, Wi-Fi, Bluetooth
373.00 €
Printer spare part
Zebra Applicator Interface Card - 1
171.00 €
Printer accessory
Zebra KIT PEEL/TEAR BAR ZT610 ZT610R
36.00 €
Printer spare part
Zebra Kit Rewind Roller ZT610 ZT610R
56.00 €
Printer spare part
Zebra Kit Cutter Upgrade ZT610 ZT610R with PCB
578.00 €
The ZT610: the top-of-the-range 4" industrial printer, shown here at 600 dpi for micro-labels.
The Zebra ZT610 is the successor to the legendary Xi series: featuring a steel frame, 24/7 reliability and first-class print quality. At 600 dpi, it prints electronic labels and tiny codes with perfect clarity.
Colour display, illuminated and colour-coded media paths and ribbon, simplified print head pressure adjustment. USB, serial, Ethernet, Bluetooth.
Highlights
- Width 4", 600 dpi
- Steel structure, 24/7 reliability
- Colour display, illuminated paths
- USB, serial, Ethernet, Bluetooth
- Ideal for micro-labels
Ideal for : Electronics, pharmaceuticals, micro-labelling, high-volume production.
Technical specifications
| Printing | |
|---|---|
| Print technology | Thermal transfer |
| Maximum resolution | 203 x 203 DPI |
| Print speed | 356 mm/sec |
| Maximum printing width | 10.4 cm |
| Vertical printing | Yes |
| Rotated printing | Yes |
| Paper handling | |
| Ribbon width | 11 cm |
| Ribbon length | 450 m |
| Maximum label length | 762 m |
| Maximum roll diameter | 20.3 cm |
| Media thickness | 0.058 - 0.25 mm |
| Core diameter | 7.62 cm |
| Ports & interfaces | |
| Connectivity technology | Wired & Wireless |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | Yes |
| Bluetooth version | 4.0 |
| USB port | Yes |
| USB 2.0 ports quantity | 3 |
| RS-232 ports | 1 |
| Performance | |
| Page description languages | ZPL, ZPL II |
| Internal memory | 1024 MB |
| Flash memory | 2048 MB |
| Built-in barcodes | 1D, 2D, AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 49, Code 93, Data Matrix, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, Micro QR Code, MicroPDF417, PDF417, POSTNET, QR Code, TLC39, UPC-A, UPC-E |
| Built-in processor | Yes |
| Number of fonts | 16 |
| Processor frequency | 800 MHz |
| Design | |
| Product colour | Black, Grey |
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 10.9 cm (4.3") |
| Colour display | Yes |
| Housing material | Metal |
| Power | |
| AC input voltage | 90 - 265 V |
| AC input frequency | 47-63 Hz |
| Operational conditions | |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage relative humidity (H-H) | 20 - 85% |
| Operating temperature (T-T) | 5 - 40 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Weight & dimensions | |
| Width | 268.2 mm |
| Depth | 505 mm |
| Height | 395.7 mm |
| Weight | 22.7 kg |
| Logistics data | |
| Harmonized System (HS) code | 84433210 |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
Why R2Scan
Authorised reseller, stock in Belgium, device configuration and commissioning, technical support and in-house repair workshop.
